Heavy Die transfer car Electric Motor Driven Rail Flatbed Transfer trolley For Industry Foundry Parts Handling

  • Application : Transfer Materials
  • Power Supply : Battery / cable / rail / busbar /
  • Table Size : Customized Size
  • Capacity : 1-300T
  • Certificates : CE ISO SGS
  • Safety facilities : remote control/PLC

We're here to help:

Easy ways to get the answers you need.

(※ Click this button to inquiry)
Share with :
  • electric-flat-bed-rail-transfer-cart
  • electric-driven-transfer-cart
  •  electric-rail-powered-transfer-cart
  •  foundry-parts-transfer-carts
Main Products
On-rail Transfer trolleys
Custom Transfer trolleys
Trackless Transfer trolleys
Industrial Trailers
Rail Flaw Detection Vehicle

Need Help?

or Email us:

sale@perfte.com

Follow Us

Facebook Linkedin
■ Overview

Heavy Die Electric Driven Rail Flatbed Transfer Cart For Industry Foundry Parts Handling

The series of Heavy Die Electric Driven Rail Flatbed Transfer Cart can run between two vertical tracks, or they can run on L-shaped or S-shaped or curved tracks, battery power can also run on cement.
In addition, Heavy Die Electric Driven Rail Flatbed Transfer Cart is specifically designed to work with cranes to transfer conductors or materials from one plant to another.
The Heavy Die Electric Driven Rail Flatbed Transfer Cart has the advantages of low body, low energy consumption, high load, flexibility, high efficiency, and easy operation.


■ Technical Data


Model

BWP-2T

BWP-10T

BWP-20T

BWP-30T

BWP-50T

BWP-63T

BWP-150T

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Ground Clearance (mm)

50

50

50

50

50

75

75

Motor Power (Kw)

1

1.6

2.2

3.5

5

6.3

15

Battery Capacity(Ah)

180

160

180

250

330

400

600

Battery Voltage(V)

24

48

48

48

48

48

72

Running Time When Full Load

4.32

4.8

4

3.5

3.3

3

2.9

Running Distance for one Charge(Km)

6.5

7.2

4.8

4.2

4

3.6

3.2

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

■ Application
 This Heavy Die Electric Driven Rail Flatbed Transfer Cart not only can transport all kinds of die, it is also can be widely applied in Metallurgy, Machinery Fabrication, Auto makers, Heavy Industrial, Light Industrial, Mold Maker, Construction Machinery maker, Shipyard, Port Cargo Yard Steel Transfer, Mining Transfer, Air and Space as well as Military industries and so on.
