LOW OPERATING NOISE
One of the most significant advantages of the electric transfer cart turntable is its low operating noise level. This quality ensures that workers and operators within the facility remain comfortable and productive throughout the day.
ENVIRONMENT
It's designed to consume the least amount of energy possible, making it cost-effective and environmentally friendly.
WIDE APPLICATION
The Turntable Rail Transfer Cart is a perfect solution for industries that require frequent material handling operations.Some common applications of this device include warehouse. manufacturing. and assembly environments. Additionally. this system can operate in a wide range of temperatures. from -40C to 50C.
SAFETY
The electric Turntable Rail Transfer Cart is designed to provide maximum safety: it is equipped with features such as emergency stops, flashing lights, safety sensors, and audible alarms. These safety features ensure that operators remain safe while using the device, even in high-pressure situations.
MAKE ON DEMAND
The electric transfer cart turntable is highly customizable to meet the specific needs of different industries and factories.This variability includes customization options for cart size, load capacity. color options, and different power options.
| Model | BZP-2T | BZP-10T | BZP-20T | BZP-30T | BZP-50T | BZP-63T | BZP-150T | |
| Rated load(T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size(mm) | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 500 | 550 | 600 | 650 | 700 | 800 | 1200 | |
| Wheel Diameter(mm) | D270 | D300 | 350 | 0400 | D500 | D600 | 中600 | |
| Wheel Quant y | 41 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Running speed(min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(Kw) | 0.8 | 1.5 | 2.5 | 4 | 5.5 | 7.5 | 15 | |
| Max Wheel Load(KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 | |
